The MXL-M-PHY-MIPI is a high-frequency low-power, Physical Layer IP compliant with the MIPI® Alliance Standard for M-PHY. The IP can be used as a physical layer for many applications, including interfaces for display, camera, audio, video, memory, power management and communication between Baseband to RFIC.

It supports the following standards: DigRF v4, CSI-3, DSI-2, Uniport-M（UniPro1.5）and JC-64.1 UFS. By using efficient BURST mode operation with scalable speeds, significant power savings can be obtained. Selection of signal slew rate and amplitude allows reduction of EMI/RFI, while maintaining low bit error rates.

M-PHY Type-I and Type-II Clocking Architectures（Source：MIPI Alliance）

The Mixel M-PHY Features：
　‧　Complies with MIPI Standard for M-PHY, Draft Specification v0.9
　‧　Dual-simplex point-to-point interface with ultra low voltage differential signaling
　‧　Slew-rate control for EMI reduction
　‧　Supports all HS modes（GEAR 1-3）
　‧　Supports all Type-I LS modes（GEAR 0-7）
　‧　Supports Type-II LS mode
　‧　1-6Gbps data rate in HS mode
　‧　0.01-576Mbps data rate in LS mode
　‧　Supports the use of optical media converters
　‧　Modular design to allow for all possible configurations
　‧　Low power dissipation
